rrent causesthe field to push sidewise on the wire. This force moves the wiresidewise and develops mechanical power. The motion of the wireinduces in it an electromotive force F which opposes the flow ofcurrent in the wire. Work is done by the external generator inforcing the current against the… … Fig. 13. nating-current dynamo are shown in Fig. 13. A wire W (per-pendicular to the plane of the figure) is moved sidewise along thedotted circle so as to cut the magnetic lines of force which eman-ate from the inwardly projecting poles of a field magnet. Whilethe wire is sweeping across a north…
