222.—Elevation of Plans in Fig. 221 (page 85). 242 DEPARTURE FROM TRADITIONAL PLAN. wrong fa9ade in his upper plan. Accordinc^ to a note on theground plan it should be at the back, and the elevation con-firms this disposition. Owing to the situation of the hall it … 33 223.—Un-named Plan and Elevation (page 34). 1. Hall. 2. Parlour. 3. Withdrawing Room. 4. Closet.5,5. Lodging. 6. Principal Stairs. 7. Buttery. 8. Back Stairs. 9. Kitchen. 10. Larder. 11. Bolting-house. 12. Pastry. can no longer obtain light from the sides, nor can there be anybay window to the…
