Easy electrical experiments and how to make them; (1918)
Dickinson, Leonard Perley, 1874- [from old catalog] · Chicago, F. J. Drake & co · leaf 42
ARMATURE-AND COMMUTATOR COMMUTATOR … SIDE: VIEW END VIEW ends project from one end of the armature. The first thing todo after seeing that the winding is smoothly in place is to applywhat are called binding wires. These are shown at B in thefigure, and are for the purpose of holding the wires firmly inplace when the armature rotates…
Electric apparatus and appliances · Electricity
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
