Automobile driving self-taught; an exhaustive treatise on the operation, management and care of motor cars (1912)
Russell, Thomas Herbert, 1862-1947 · Chicago, Charles C. Thompson co. · leaf 169
A brush B held in an insulating brush-holder A presses on theenlarged head C of the connector bolt D, thus leading the armaturecurrent to the external circuit from 11. One lead 10-11 carries thearmature current to the primary coil 10-7. Instead of depending onthe armature ground connecting with the…
Automobiles
Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
