Easy steps in architecture and architectural drawing .. (1915)
Hodgson, Frederick Thomas, 1836- [from old catalog] · Chicago, Ill., Printed by F. J. Drake & co. · leaf 387
Fig. I. They may be clamped on the ends with stuffabout 1% inches wide and the thickness of theboard, or they maybe held together with battenseither screwed on to the underside as shown at … Fig. 2. Fig. I, or dovetailed into the board across thegrain as shown a^ rig. 2. At Fig. 3 a much
Architecture · Architectural drawing
