ivide c, b, b, d, intotwo equal parts in the points e, and f, withradius e, c, describe an arc cutting in the point i;from i, with i, a, describe the arc b, a, h. Fromthe point b, set off the distance e, f, to the pointj; and through j, draw a line k, k, parallel to c,d. From j, with the distance… … Fig. 232. the leading curves thus described as shown inthe drawing. The skeleton shown in the illustration, Fig.232, exhibits an ornament drawn altogether withthe compass. The centers are all shown andlettered for reference; r being the general 216 ARCHITECTURAL DRAWING SELF TAUGHT
