ofcharacter- and decoration—it sometimes is with-out necking, sometimes with; which may eitherbe plain or decorated, to suit the entire design.The capital may also be modified in its pro-portionSj first as regards its general proportionto the column; secondly, as regards the size ofthe volutes… … Fig. 241. ARCHITECTURAL DRAWING SELF TAUGHT 235 also of the volutes may be either single ormaniold, and the eye or center of the spiralmay be made larger or smaller, flat or convex,or curved as a rosette. Fig. 242 represents an example of the Corin-thian order, from the Arch of Hadrian, atAthens.…
