Easy steps in architecture and architectural drawing .. (1915)
Hodgson, Frederick Thomas, 1836- [from old catalog] · Chicago, Ill., Printed by F. J. Drake & co. · leaf 83
man work present? A. The elevation of the interior, and the divisioninto the triple range of pier arch, triforium, and cleres-tory. This is a great advance toward the pure Gothicprinciple, but it is as yet only partial, as the horizontallines between each remained unbroken. Q. What further advance… … Fig. 77. Fig. 78. running up the piers of the roof, dividing the triforiumand clerestory into parts. The effect of the horizontaldivision into layers of the Romanesque style is nowgone, and the vertical principle of Gothic architecturebegins to establish itself. In many later examples ofNorman…
Architecture · Architectural drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
