are theblade (a) and handle (h). These parts are riveted firmlytogether so that they form a right angle. The blade isgraduated in inches, halves, quarters, and eighths. Try-squares may also be obtained graduated in the metricsystem. The blade differs in length from 2 to 12 inches. A 6-inch blade is… … are more ex-pensive thannickel-plated ^^^^ 5handles. 6. Bevel. — The bevel consists essen-tially of a handle (6) with a movable Bevel, a, blade; 6, handle;c, set-screw. 28 EDUCATIONAL WOODWORKING lio ;;iii ;.;ii2;,>|3 \y:,, „,,,, oi , si ! 110, Ili, 112 , iii , iiVTils Fig. 6, — Framing square…
