Educational woodworking for home and school (1908)
Park, Joseph C. (Joseph Charles), b. 1872 · New York, The Macmillan company · leaf 57
Fig. 15. — Marking gauge, a, bar; &, head; c, thumbscrew; d, point. 36 EDUCATIONAL WOODWORKING … Fig. 10. — Mortise gauge, a, bar; b, head: c,thumbscrew ; </, fixed point; e, movable point;/, set screw for movable point. edge. It is con-structed like amarking gaugeexcept that ithas two points,one fixed and amovable point.Its principal use is in the making of mortise and tenonjoints, from…
Woodwork (Manual training)
