The elasticity and resistance of the materials of engineering (1883)
Burr, William H. (William Hubert), 1851-1934 · New York, J. Wiley & sons · leaf 628
e riveted ; Fig. 3 is a * butt joint with a singlebutt strap and single riveted ; while Figs. 4, 5 and 6 are buttjoints with double butt straps, Fig. 4 being single rivetedwhile the others are double riveted. Fig. 5 shows zigzagriveting and Fig. 6 chain riveting. All these joints are de-signed to… … ) Fig. 1
Strength of materials · Building materials
