The elasticity and resistance of the materials of engineering (1883)
Burr, William H. (William Hubert), 1851-1934 · New York, J. Wiley & sons · leaf 665
ent, of thatofthe solid plate. Although the test specimens were altogether too small tobe of the greatest value, the results are most excellent. The value of a welded joint depends as well upon thenature of the material welded as upon the manipulation duringwelding. Art. 75.—Pin Connection. A pin… … Fig.l The head of the eye bar (one is shown in elevation in Fig.2) requires the greatest care in its formation. It is imperfect Art. 75.] EYE BAR HEADS. 645 unless it be so proportioned that when the eye bar is tested tofailure, fracture will be as likely to take place in the body ofthe bar as in…
Strength of materials · Building materials
