s and instruments which may be calculated by I2E. Method of Dr. Humpner. Iron iioss.— The following diagramshows the connections for Dr. Sumpners test for iron losses. The low-pressure side is connected to a source of current of the same pressure atwhich the transformer is expected to work, thus… … Fig. 70. Dr. Sumpners Test for Iron Losses. Copper Iioss. —The next diagram shows the connections for determin-ing the copper losses. The low-pressure side is short-circuited through anammeter, the high-pressure side being connected to the 100-volt supply-mains. The resistance R is then adjusted to…
