railway work, the switch-boxes are preferable installed outside the track, Avhile the buttons areplaced between the rails and mounted on a light metal tie, as shown in Fig. 542 ELECTRIC STREET RAILWAYS. The operation of the system is exactly the same as in open-track work.Connecting wires pass from… … CHANNEL IRON Fig. 104. Section of Track Equipped for Street Railway Service. When, as is sometimes necessary, the buttons are placed in a single row,it is necessary that the pick-up current should be of the same voltageas that of the main circuit, and consequently the car-wiring indicated inFig. 96…
