es System with Magneto Transmitters and SignalingBatteries. In Fig. 35 a very similar arrangement is shown, the only difference beingthe use of magneto generators, G, in the place of the signaling batteries,B, of Fig. 34, and the substitution of magneto bells for the simple bells usedin the first… … Fig. 35. Series System with Magneto Transmitters and Generators. spindle which short-circuits the armature of the magneto whenever thespindle is at rest. The act of turning the handle of the magneto removesthe short-circuit and allows the induced current to pass out to the line.When this type of…
