Hutton, Frederick Remsen, 1853- [from old catalog] · New York, J. Wiley & sons; [etc., etc.] · leaf 170
Fig. 105.—Grouping of Cylinders of Triple-expansion Engines. SIMPLE AND COMPOUND ENGINES, ni / p. r^ M]P. L.P. .41 MLP. 3 MlP. 2| ^5. LP. 4| T … Fig. io6.—Grouping of Cylinders in Quadruple-expansion Engines. 134 MECHANICAL ENGINEERING OF POWER PLANTS. cylinder. Reheating would supply additional heat to com-pensate for that consumed without return in the high-pressurecylinder, and would vaporize the water of condensation fromdoing work…
Mechanical engineering · Steam power plants
