each of these arcs is pivoted a teiescope. tbe pivot ofwhich is connected to a battery B The telescopes are in electrical contactwith the arcs. These metallic arcs are connected at their extremities witha galvanometer, c, the whole forming a Wheatstone bridge, whose arms areaa bb. When the… … Fig. 10. Fig. 11. is noted. By swinging the telescope at F around till the needle of thegalvanometer indicates zero, the bridge balances, tbe telescope beingparallel to the one at C, and the arc or angle DF — FE is equal to theangle at A. From this the distance AC can be calculated, or read…
