Electrical installations of electric light, power, traction and industrial electrical machinery (1902)
Kennedy, Rankin, d. 1917 · Edinburgh T.C. & E.C. Jack · leaf 249
site .senses. They also pass upwardsthrough the brake pole-pieces E E and the upper iron bridge-pieceG. O is the brake-disc; H the correcting coils for tluid frictionerror; F the reduced saturated neck of one of the brake pole-pieces ; K K insulated strips of copper, conducting the current fromthe… … Fig. 249.—Chamberlain & Hookham Continuous Current Meter Continuous Current Motor Meters The armature is slit radially for about one-third of its diameter allround, leaving a continuous area of copper in the centre. The action of the meter is as follows: Owing to the greatlength of the magnet A…
