R Y v Rr Then -: 5 = —, Y = i4 + /? r A + R In fault testing the negative pole of the batteryis preferably connected to the cable. If the posi-tive pole be applied and there be a bared spot inthe insulation, this bared spot will be acted on bythe current, and apparently improved, but thechloride of… … Fig. 92. 162 ELECTRICAL INSTRUMENTS. One end of the cable conductor is connected to agalvanometer the second terminal of the latterbeing grounded through a battery. The cable is wound from one reel to the other,the slack passing through the water in the tank.As soon as a fault reaches the wTater,…
