shown in Fig. 153 148 ELECTRICAL MACHINERY and is known as a pulsating current. To obtain a constantcurrent for a given value of resistance in the external circuit,or, as it is usually called, a direct current, it is necessary to havea number of coils on the armature and the ring divided intoas… … Fig. 154.—Diagrammatic representation of ring-armature type generator. the complete layout of a dynamo-electric machine having anarmature of the ring type. Coils of wire, designated fieldcoils, are placed on the polepieces. The winding on thearmature is shown, for simplicitys sake, to be conlinuous…
