Electrical machinery; a practical study course on installation, operation and maintenance (1921)
Annett, Fred Anzley · New York [etc.] McGraw-Hill book company · leaf 306
nductances. This will be mo-» readily understood by referring THREE-WIRE SYSTEMS 289 to Fig. 325. At the instant shown in Fig. 321, if the inductances weredisconnected from the brushes on the shp rings and connected acrossthe hue, as in Fig. 325, the conditions would bo identically alike exceptthat… … I=J5 Fig. 325.—Same as Fig. .S24, Init v.-ith the iiiductaiice coimected to the external circuit. the total power supplied by the generator equaling £7=220X85 = 18,700watts, which check up against the lamp load of 17,6:^0 watts, plus thepower required by Li and L-2 at this instant, to excite them,…
Electric machinery
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
