Electrical machinery; a practical study course on installation, operation and maintenance (1921)
Annett, Fred Anzley · New York [etc.] McGraw-Hill book company · leaf 398
Fig. 443 Fig. 444 Fig. 443.—Shows construction of transformer core.Fig. 444.—Shows how eddy currents are induced in transformer core. values that involve large losses. For simplicity of construc-tion, the individual sheets of iron are not punched out as acomplete loop, as in Fig. 443, but in one…
Electric machinery
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
