FlG. 35 Fia. 36 Figs. 35 and 3G.—Primary battery cells. Electric Pressure and Temperature.—An analogy of tliisdifference of electric pressure is found in heat. If we wishheat to flow from one body into anotlier, a difference of Heat. Insulator … Fig. 37.—Temperature analogy of battery cell, Fig. 35. tcmpnraturo and also a path for llie heat to flow must beprovided. For cxnuiple, consider the conditions in Fig. 37. FUNDAMENTALS OF THE ELECTRIC CIRCUIT 31 Here are two metal blocks, A and B, with a heat insulator Cbetween them such as a…
