Modern painting, hardwood finishing and sign writing (1918)
Armstrong, George D, Hodgson, Frederick Thomas, 1836-1919, Delamotte, Frances George · Chicago, Ill., F. J. Drake, expressly for Sears, Roebuck · leaf 555
n of stock; B, the wedge; C, cuttingiron; D, back iron; E, the screw for fastening ironstogether; and F is the mouth through which theshavings pass upwards. A plane is simply a copyingtool, and a notch in the plane-iron at once proves thatthe pattern produced corresponds with the edge ofthe… … Fig. 87 HARDWOOD FINISHER 85 to be produced on the wood, a tool is used with around edge of exactly similar form to the hollow wewish produced. In machine planing the pattern is theedge of the tool, which produces a similar surfaceupon the wood. Direction of Grain in Planes.—For flat planes such…
Painting, Industrial · Wood finishing · Lettering
