International Library of Technology · Scranton, International Textbook Co. · leaf 238
ng is a stationary soft iron cylinder C, supported in placeby a screw J/passing through a lug on the brass plate B.This cylinder being of less diameter than the openingthrough the pole-pieces, there is left a narrow gap betweenthe pole-pieces and the iron core, as shown. The lines offorce from the… … Fig. loas.aluminum or thin copper bobbin, which is suspended verti-cally between two delicate jeweled bearings. Two flathorizontal spiral springs 5, 5 oppose the tendency of thecoil to rotate, and at the same time conduct the current tothe suspended coil. A thin aluminum pointer P, attached at…
Electrical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Electric engineering.], 1902, leaf 238](https://img.insideoutlibrary.com/img/1024/ia-electricengineer01inte-238-105.webp)
