Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 44

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 44
than 47. THERMOSTAT.For an incubator. A coilof zinc and steel ribbonfastened together by rivetsor solder is fixed at its cen-ter end to a block in theincubator chamber and at-tached by a lever to adamper and to a lever onthe wick gear, and controlsboth air inlet and flame.The zinc should be… … balancing lever and connections ; A, air inlet cylinder ; B, lamp chim-ney, all of sheet iron ; O, damper rod ; D, wick rod. 40 MEASUREMENT OF POWER. SPRINGS.
