Fig. 1390. lengths, the commutator bearing being shorter. It will alsobe noticed that the rocker-arm is supported in a ratherdifferent manner from that described in connection withsmaller machines. The frame as a whole is fitted to a base-plate b, and slides along it in a direction perpendicular to…
