International Library of Technology · Scranton, International Textbook Co. · leaf 136
rminal blocks isshown in Fig. 1401. The end a is of such a size as to entereasily into the hole in the block, and is intended to be flushwith the edge of the block when in position. The lead issoldered in, as already described. The edge e should not beleft square, but must be rounded, as shown, in… … Fig. 1399. 2512 DYNAMO-ELECTRIC MACHINE DESIGN.
Electrical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Electric engineering.], 1902, leaf 136](https://img.insideoutlibrary.com/img/1024/ia-electricengineer02inte-136-51.webp)
![An illustration from [Electric engineering.] (1902)](https://img.insideoutlibrary.com/img/200/ia-electricengineer03inte-649-385.webp)
