/H \U 1^ u/ Fig. 1403.Fig-. 1400, but the cable tips enter only half the distancehence two may be used—one from either side. DYNAMO-ELECTRIC MACHINE DESIGN. 2513 3771. For a compound-wound dynamo, the connectionsof the series coils to each other are made with cast-brassclamps, Hke that shown in…
