\ / … Fig. 1422.magnetized. The handle is then moved over slowly and lefton the last point when the motor has attained its full speed. SERIES-MOTOR CONNECTIONS. 3808. The connections for a series motor are shownin Fig. 1423. Connection is made to the mains through aswitch and fuse block as before. The…
