International Library of Technology · Scranton, International Textbook Co. · leaf 299
ies, and the terminals d, U attached to the light collectorrings 5, If-. The angular distance by which the center of set Bis displaced from set A is equivalent to 90°, or \ cycle,as indicated in the figure, the angular distance from A^to A^being equivalent to 360°, or one complete cycle. 3976. Fig.… … Fig. 1527.windings are here represented by coils 1 and 2 connected tothe collector rings a, a and b, b. These windings have no CURRENT APPARATUS. 2673 electrical connection with each other and connect to twodistinct circuits. 3977. Sometimes, instead of using two distinct circuitswith four…
Electrical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Electric engineering.], 1902, leaf 299](https://img.insideoutlibrary.com/img/1024/ia-electricengineer02inte-299-161.webp)
![An illustration from [Electric engineering.] (1902)](https://img.insideoutlibrary.com/img/200/ia-electricengineer04inte-48-12.webp)
