International Library of Technology · Scranton, International Textbook Co. · leaf 390
indicated by the dotted and dotand dash lines. Starting from the collector ring r^, we connectto the bottom conductor in slot 1, from there we pass to thecorresponding slot under the next pole, that is, slot 7, andconnect to the top conductor in that slot. In this way wepass twice around the…
Electrical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Electric engineering.], 1902, leaf 390](https://img.insideoutlibrary.com/img/1024/ia-electricengineer02inte-390-215.webp)
