International Library of Technology · Scranton, International Textbook Co. · leaf 410
6. ^ 4116. Fig. 1617 shows the insulation for a two-layerbar-wound armature with straight slots. This style ofslot would be suitable for the bar wind-ing shown in Fig. 1594. In such cases thebars have to be placed in the slots fromthe top, the bent ends preventing their be-ing pushed in from the…
Electrical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Electric engineering.], 1902, leaf 410](https://img.insideoutlibrary.com/img/1024/ia-electricengineer02inte-410-236.webp)
