or alternators and continuous-current machines, because no room need generally be allowedfor collector rings. Fig. 1686 shows the induction motorwhich has been worked out. This will give an idea as to thestyle of shaft used for such machines. FIELD FRAME, BEr)-I>LATE, ETC. 4270. The arrangement… … CURRENT APPARATUS. 2895 shown. It serves the double purpose of supporting the fieldstampings and forming a base for the machine. In some ofthe larger sizes of induction motors, the field frame is boltedto a separate bed in the same manner as shown for the fieldof the alternator. For machines of…
