ties, whereground is very expensive. For small plants, where thefirst cost must be kept down and where economy of space isnot necessary, belted units are still installed in many cases. § 14 ELECTRIC TRANSMISSION. 11 1-4. Fig. 5 shows the arrangement of a typical moderncentral station designed for a… … Fig. 5. the engines or dynamos may be easily handled in caserepairs are necessary. The condenser F is situated in thebasement, and in this case both the air pump and circula-ting pump are driven by electric motors. The boiler roomis situated on the left and is separated from the engine roomby a…
