International Library of Technology · Scranton, International Textbook Co. · leaf 287
se cur-rents at a frequency of 60 cycles. The revolving field isseen at A, but a better idea as to the construction of themachine will be obtained by referring to Fig. 53. Therevolving field consists of a steel ring B supported by thespider c c. The ring B carries the laminated pole pieces D,which… … Fig. 52. machines, is wound with copper strip placed on edge. Thesecoils are connected in series and their terminals brought to
Electrical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Electric engineering.], 1902, leaf 287](https://img.insideoutlibrary.com/img/1024/ia-electricengineer03inte-287-163.webp)
