each step as the arm is movedaround. This scheme is used in the rheostat shown inFig. 21, and will be understood by referring to Fig. 22. The regular rheostat con-tacts are arranged asusual and are shown at1, 2, 3, etc. Instead, how-ever, of using a simplecontact arm, the armis provided with… … Multiplyingfiesistance § 20 ELECTRIC RAILWAYS. 53 approximately equal to one of the resistance sections onthe rheostat. By tracing- out the current, it will be seenthat c is placed in parallel with the step on Avhich the armrests, and it has the effect of practically halving the resist-ance of each…
