latively low core loss shouldbe selected so as to increasethe all-day efficiency. Iffully loaded all day, thelosses should be divided about equally between the copper and theiron losses. Regulation. By regulation of a transformer is meant thepercentage drop in the secondary voltage from no load to… … Fig. 33. Transformer Connections from ThreePhase to Six-Phase for Rotary Converter 62 POWER TRANSMISSION 53 10 per cent, or less, of that due to the resistance drop. For non-inductive load (power factor= unity) the regulation is from 1 to 3per cent in good transformers. With induction load this is…
