Electricians' operating and testing manual; (1910)
Horstmann, Henry C. [from old catalog], Tousley, Victor Hugo, 1875- [from old catalog] joint author · Chicago, F. H. Drake & co · leaf 64
pass 62 Operating and Testing out of the influence of the fields. It is very import-ant to see that the commutator is always set with re-gard to this. The Thomson-Houston is another type of open cir-cuit dynamo armature. The nature of its winding isshown in Figure 43. One end of each coil is… … Figure 43 mum of which it may be capable and probably burnout. The greater the current the greater will be thepressure, but after the fields have become fully sat-urated the increase in E.M.F. will be small. Figure44 shows the characteristic curve of such dynamos.Such curves are obtained by…
Electrical engineering · Electric testing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
