Electricity and magnetism for advanced students (1920)
Starling, Sydney George, 1873- · London Longmans, Green · leaf 165
guard-ring, so that the irregu-larity of the field does not occur at theedge of A, but at that of the guard-ring G. There is still a slight irregu-larity in the field where the gap betweenA and G occurs, but if this gap is notvery wide, Kelvin found that the effec-tive area of the plate is the… … Fig. 166. the figure being in section, h, the guard-ring, and h, the plate, can beinsulated or connected together, and the parallel earthed plate e canbe raised or lowered by means of the micrometer screw/. The distanceapart of the plates is measured by bringing e into contact with h andh. The…
Electricity · Magnetism
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
