The electric motor and the transmission of power (1906)
Houston, Edwin J. (Edwin James), 1847-1914, Kennelly, Arthur E. (Arthur Edwin), 1861-1939, joint author · New York : McGraw Pub. Co. · leaf 199
Fig. 48.—Details of Self-Oiling Bearing. its brass rings, are shown in greater detailin Fig, 48. The field magnets, the function of whichis to produce the flux passing through thearmature, consist essentially of coils of in-sulated wire, provided with cores and pole THE TRAlSrSMISSION OF POWER. 191… … Fig. 49.—Skeleton of Motor Parts. at 3 and 2, respectively. The coils ofinsulated wire which surround them are inpractice wound on spools so that the entirecoil can be readily removed from the core.Such a coil is shown at -4, in Fig. 30. The 192 THE ELECTRIC MOTOR AND cast-iron base of the macliine…
Electric motors
