An elementary book on electricity and magnetism and their applications (1919)
Jackson, Dugald C. (Dugald Caleb), 1865-1951, Jackson, John Price, b. 1868, Black, Newton Henry, b. 1874 · New York, The Macmillian Co · leaf 410
ts, the core,when built up and clamped together, hasbut little more reluctance than it wouldhave if each lamination were in one piece. The most modern type is really a modification of the coretype, with which are combined many of the advantages ofthe shell type. It has the windings or coils on one… … Fig. 254. — A small shell-type transformer. Ironlaminations vertical. §|c |l| 0 c o a 11 o c Fig. 255.— Lamina-tions of iron corebuilt of pieces.
Electricity · Magnetism
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
