Elementary cabinetwork for manual training classes (1909)
Selden, Frank Henry. [from old catalog] · Chicago, New York [etc.] Rand, McNally & company · leaf 108
aw light pencil lines acrossthe grain, then draw the gauge lines, being carefulnot to make any lines beyond the pencil lines.Draw pencil and gauge lines on both top and bot-tom sides. Set the gauge to the line nearest theface edge, and draw all the lines at this distancefrom the edge for both… … for the tapering wedges.See drawing (Fig. 87).Remember that theseholes are not of the samesize on both the upper andlower sides of the shelf.Before cutting thepiece in two, lay out theopenings for the bottomends and bore the holesat the corners; also borethe holes for the mortises(Fig. 86). After…
Cabinetwork
