Elementary cabinetwork for manual training classes (1909)
Selden, Frank Henry. [from old catalog] · Chicago, New York [etc.] Rand, McNally & company · leaf 171
the sides of Fig. 160. Adjust-the stiles near the bottom end. The ^^^ ^^^upper end of the back is supported on the adjustingrod, which passes through holes in the narrow endof the arms. In Fig. 158 these rods are similarlyplaced except that they are cut short, so that theirends do not extend… … used. If ball-bearing ballcasters are used, theyshould be set up into the Fig. 161. Cube on end of rod ^^^ ^^ ^^^ ^^^ ^^ ^5 ^^ ^^ scarcely visible. One-fourth inch projection will do.The thickness of the cushions should be consid-ered also in planning the height of the rails and arms. HALL SEATHALL…
Cabinetwork
