Fig. 56. Rivet Ready for DrivingCourtesy Vulcan Engineering Sales Company Riveting Machines in Shop. In the shop, rivets are driven withan hydraulic riveter, Fig. 54, or a pneumatic riveter, Fig. 55. The … Fig. 57. Three Stages in Process of Riveting machine consists essentially of a yoke which spans the membersto be riveted, Fig. 56. On the outer arm of the yoke is a die which STEEL CONSTRUCTION 01 fits over the head on the rivet; the other arm carries a similar die,or rivet set, which pushes…
Building, Iron and steel · Steel, Structural · Theses
Internet Archive · University of Illinois Urbana-Champaign · Public Domain Mark 1.0. Free to use for anything.
