Elementary cabinetwork for manual training classes (1909)
Selden, Frank Henry. [from old catalog] · Chicago, New York [etc.] Rand, McNally & company · leaf 273
scutch-eon like Fig. 262, holes are bored for the key and thelock then fastened in place. The escutcheon is thelast part to locate, and is placed to correspond withthe pin over which the key slips, or with the keyhole. If a roun descutcheon(Fig. 263)is used, thehole for itmust be boredbefore… … TOOLS AND MATERIALS 267 used instead of a plow for grooving the stiles and railsaround a panel. Use it carefully, and keep it sharp.Your chief difficulty in using this plane is to hold itvertically. If you do not, the tongue which it makeswill be too narrow and the groove too wide. Asthere is no…
Cabinetwork
