Appletons' cyclopaedia of applied mechanics: a dictionary of mechanical engineering and the mechanical arts (1880)

D. Appleton and Company, Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 571

An illustration from Appletons' cyclopaedia of applied mechanics: a dictionary of mechanical engineering and the mechanical arts, 1880, leaf 571
shown, allows both of the cutters to act; and the cutters being placed at a suitable distance apart,a tonguing plane is made. The guide or fence, which is hung on a pivot at its centre, may beswung around, end for end; thus one of the cutters will be covered, and the guide held in a newposition,…

Mechanical engineering -- Dictionaries
