Fig. 68. Testing with jraming-square glue. Apply the try-square to every joint, as shownin Fig. 67. Apply the large steel square whereverpracticable as shown in Fig. 68. Look for wind from … Fig. 6g. Looking for wind. (5^^ Fig. 184.) 90 ELEMENTARY CABINETWORK all sides in every piece (Figs. 69 and 70). Ifpiece is irregular or the face surfaces obscured,straight edges or the blades of framing squaresthe piece to assist in testingfor wind. Always test fromthe face edges or face sides.To…
