Elementary course in woodwork ; designed for use in high and technical schools, with one hundred and thirty-four illustrations, by George Alexander Ross (1901)
Ross, George Alexander · Chicago, New York, A. Flanagan Company · leaf 33
and place the try-square (Fig. 29)against the edge of the plank, and draw a line alongthe blade through the point marked. The piece should be marked out larger than the fin-ished exercise so that there will be stock enough in the ELEMENTARY COURSE IN WOODWORK. 29 piece to perform the operations… … Fig. 28. line, taking care that the kerf is square to the sideof the plank; then take the cross-cut saw, and sawacross the line marked. Hold the cross-cut saw as inFig. 30. After having cut the piece from the plank take thejack-plane and put it in good condition for work. Asectional view of the…
Woodwork (Manual training)
