Small, Sidney Aylmer, 1876- [from old catalog] · Chicago, F. J. Drake & co · leaf 296
e we increasing the con- PARALLEL CIRCUITS 297 ductivity between these two points, and the less is theresistance becoming, but providing the dynamo main-tains the pressure, no alteration would take place in thevalue of the current in any individual conductor. Eachseparate conductor would act… … Fig. 143. Elydraulic Circuit with. By-pass. Effects of Current. Imagine a circuit like Fig. 144 containing in order 1. A galvanometer or current meter. 2. An electromagnet. 3. An apparatus for electrolysing water or a gas volt-ameter. 4. A copper plating bath or copper voltameter. 298 ELEMENTARY…
Electricity
